9 Storage Management for VLDBs

Hardware-Based Mirroring

Most external storage devices provide support for different RAID (Redundant Array of Inexpensive Disks) levels. The most commonly used high availability hardware RAID levels in VLDB environments are RAID 1 and RAID 5. Though less commonly used in VLDB environments, other high availability RAID levels can also be used.

Mirroring using ASM

Automatic Storage Manager (ASM) provides software-based mirroring capabilities. ASM provides support for normal redundancy (mirroring) and high redundancy (triple mirroring). ASM also supports the use of external redundancy, in which case ASM will not perform additional mirroring. ASM normal redundancy can be compared to RAID 1 hardware mirroring.

With ASM mirroring, the mirror is produced by the database servers. As a result writes require more I/O throughput when using ASM mirroring compared to using hardware-based mirroring. Depending on your configuration and the speed of the hardware RAID controllers, ASM mirroring or hardware RAID may introduce a bottleneck for data loads.

In ASM, the definition of failure groups enables redundancy, as ASM will mirror data across the boundaries of the failure group. For example, in a VLDB environment, you can define one failure group per disk array, in which case ASM will make sure to place mirrored data on a different disk array. That way, you could not only survive a failure of a single disk in a disk array, but you could even survive the crash of an entire disk array or failure of all channels to that disk array. Hardware RAID configurations typically do not support this kind of fault tolerance.

ASM using normal redundancy requires double the amount of disk space needed to store the data. High redundancy requires triple the amount of disk space.

Hardware-Based Striping

Most external storage devices provide striping capabilities. The most commonly used striping techniques to improve storage performance are RAID 0 and RAID 5.

Striping Using ASM

Automatic Storage Manager (ASM) always stripes across all devices presented to it in the context of a disk group. A disk group is a logical storage pool in which you create data files. The default ASM stripe size is 1 MB, which is a good stripe size for a VLDB.

Oracle recommends that you use disks with the same performance characteristics in a disk group. All disks in a disk group should also be the same size for optimum data distribution and hence optimum performance and throughput. The disk group should span as many physical spindles as possible in order to get the best performance. The disk group configuration for a VLDB does not have to be different from the disk group configuration for a non-VLDB.

ASM can be used on top of already striped storage devices. If you use such a configuration, then make sure not to introduce hotspots by defining disk groups that span logical devices which physically may be using the same resource (disk, controller, or channel to disk) rather than other available resources. Always make sure that ASM stripes are distributed equally across all physical devices.

ILM

In an Information Lifecycle Management environment, you cannot use striping across all devices, because all data would then be distributed across all storage pools. In an ILM environment, different storage pools typically have different performance characteristics. Therefore, tablespaces should not span storage pools, and hence data files for the same tablespace should not be stored in multiple storage pools.

Storage in an ILM environment should be configured to use striping across all devices in a storage pool. If you use ASM, then separate disk groups for different storage pools should be created. Using this approach, tablespaces will not store data files in different disk groups. Data can be moved online between tablespaces using partition movement operations in the case of partitioned tables, or using the DBMS_REDEFINITION package when the tables are not partitioned.

Partition Placement

Partition placement is not a concern if you stripe across all available devices and distribute the load across all available resources. If you cannot stripe data files across all available devices, then consider partition placement to optimize the use of all available resources (physical disk spindles, disk controllers, and channels to disk).

I/O-intensive queries or DML operations should make optimal use of all available resources. Storing database object partitions in specific tablespaces, each of which uses a different set of hardware resources, enables you to use all resources for operations against a single partitioned database object. Make sure that I/O-intensive operations can use all resources by using an appropriate partitioning technique.

Hash partitioning and hash subpartitioning on a unique or almost unique column or set of columns with the number of hash partitions equal to a power of 2 is the only technique likely to result in an even workload distribution when using partition placement to optimize I/O resource utilization. Other partitioning and subpartitioning techniques may yield similar benefits depending on your application.

Bigfile Tablespaces

Oracle Database enables the creation of bigfile tablespaces. A bigfile tablespace consists of a single data or temp file which can be up to 128 TB in size. The use of bigfile tablespaces can significantly reduce the number of data files for your database. Oracle Database 11g introduces parallel RMAN backup and restore on single data files.

As a result, there is no disadvantage to using bigfile tablespaces and you may choose to use bigfile tablespaces in order to significantly reduce the number of data and temp files.

File allocation is a serial process. If you use automatic allocation for your tables and automatically extensible data files, then a large data load can be impacted by the amount of time it takes to extend the file, regardless of whether you use BigFile tablespaces. However, if you pre-allocate data files and you use multiple data files, then you can spawn multiple processes to add data files concurrently.

Stripe and Mirror Everything (S.A.M.E.)

The S.A.M.E. (Stripe and Mirror Everything) methodology has been recommended by Oracle for many years and is an approach to optimize high availability, performance, and manageability. In order to simplify the configuration further, a fixed stripe size of 1 MB is recommended in the S.A.M.E. methodology as a good starting point for both OLTP and data warehouse systems. ASM implements the S.A.M.E. methodology and adds automation on top of it.

S.A.M.E. and Manageability

In order to achieve maximum performance, the S.A.M.E. methodology proposes to stripe across as many physical devices as possible. This can be achieved without ASM, but if the storage configuration changes, for example, by adding or removing devices, then the layout of the database files on the devices should change. ASM performs this task automatically in the background. In most non-ASM environments, re-striping is a major task that often involves manual intervention.

In an ILM environment, you apply the S.A.M.E. methodology to every storage pool.
